Transition Composite Push to Connect Fittings

Transition composite push-to-connect fittings are specialized connectors that bridge the gap between different tubing or pipe standards, from an inch tube to a metric thread or metric tube to an inch thread. The push-to-connect fittings use a durable, lightweight polymer body combined with metal threads for easy, tool-free installation. These push fittings do not have universal threads; however, they have the full standard threads. Different styles are available to easily distinguish from each other, such as white thread sealant in R (BSPT), O-Ring in G (BSPP), and gray thread sealant in NPT.

Polyconn supplies high-quality transition composite push-to-connect fittings to suit any pneumatic application. Contact our team to find the right push fitting for you or request a quote for more detailed specifications.

Transition Composite Push Fittings Specifications

Polyconn’s transition composite push-to-connect fittings are made with high-quality materials to ensure peak performance in several pneumatic applications. The specifications are designed to endure harsh environments to suit any need. Specifications of Polyconn’s transition composite push-to-connect fittings include:

Temperature Range: 32°F - 140°F (0°C - 60°C)
Pressure Range: 0-150 PSI
Vacuum Rating: To -29.5” Hg

Features of Transition Composite Push-to-Connect Fittings

Polyconn’s composite fittings have an advanced design for a strong grip on the tubing with ease of installation and removal. All of our transition composite push fittings assist with converting different tubing and pipe standards for maximum efficiency. Several features of Polyconn’s transition composite push-to-connect fittings include:

Stainless steel gripping ring for several tubing options
Nickel-plated brass components for corrosion resistance and long life
BSPT, BSPP, and NPT threads available
Pre-applied sealant on tapered threads and recessed O-ring on parallel threads
Gripping teeth independent of the collet for firmer connections
Easy to install and remove
Custom colored collets available upon request

Transition Composite Fittings Applications

The unique design and ability to transition between imperial and metric threads and tubing make transition composite push-to-connect fittings ideal for several pneumatic applications across many industries. The high temperature ratings and features ensure these push fittings can endure harsh environments. Many common applications of transition composite push-to-connect fittings include:

Transition between types of tubing in fluid applications
Provide secure connections for air cylinders, vacuum lines, and automation equipment in robotics
Heavy-duty trucks, trailers, and rail vehicles in automotive and transportation
Operate cab controls, air-operated seats, automatic windows, and operating gauges in pneumatic controls

Available Tubing for Transition Composite Push-to-Connect Fittings

Polyconn offers several types of tubing or hoses to complete your pneumatic application and be a one-stop shop for all your needs. Our transition composite push fittings are designed for several options, including:

Additionally, we offer several metric tubing products to enhance the use of the transition composite push fittings, depending on your needs.

Why Polyconn for Transition Composite Push Fittings

Since 1981, Polyconn has been the go-to pneumatic parts and components supplier across various industries for OEMs, MROs, and distributors. We strive to provide our customers with the uncompromising quality and excellent service they deserve. Our continuous improvement ensures growth for our products and builds lasting relationships with each order. View our catalogs and see how Polyconn can supply you with quality transition composite push fittings and other pneumatic components for all your needs!

Contact us for more information about our transition composite push-to-connect fittings, or call us at 763-559-0388 to speak to a real representative about our quality pneumatic components. Additionally, request a quote for more detailed pricing options.
